Home Appliance Testing Equipment Current-Carrying Hoses Crushing Resistance Test

Name: Home Appliance Testing Equipment CurrentCarrying Hoses Crushing Resistance Test
Brand: HongCe
Price: 1 USD

Best Home Appliance Testing Equipment Current-Carrying Hoses Crushing Resistance Test wholesale

Brand Name : HongCe

Model Number : HJ0614

Certification : calibration certificate (cost additional)

Place of Origin : China

MOQ : 1 set

Price : Negotiatable

Payment Terms : T/T

Supply Ability : 5 set /month

Delivery Time : 30 days

Packaging Details : plywood

Warranty : 1 Year

Product name : Current-Carrying Hoses Crushing Resistance Tester

Usage : Crushing Resistance Test

Test Sample : Current-Carrying Hoses

Standard : IEC60335-2-2

Applied force : 1.5kN

Pressure speed : 50±5mm/min

Steel plate : 10mm*50mm

Contact Now

Home Appliance Testing Equipment Current-Carrying Hoses Crushing Resistance Test

Standard of Home Appliance Testing Equipment:

IEC60335-2-2 Household and similar electrical appliances – Safety – Part 2-2: Particular requirements for vacuum cleaners and water-suction cleaning appliances clause 21.101

Purpose of Home Appliance Testing Equipment:

It is used to test whether the Current-carrying hoses is resistant to crushing.

Feature of Home Appliance Testing Equipment

During the test, the current carrying hose is placed between the upper and lower pressure plates of the equipment (length and width 100X50m, long side rounded), the hose axis is at a right Angle to the long side of the pressure plate, and one end is about 350m from the edge of the pressure plate. After starting the equipment, the upper pressure plate squeezes the current carrying hose at a speed of 505mm/min until the pressure reaches 1.5kN, and then releases the pressure. Then the hose is tested for electrical strength.

Technical Parameters:

NO.	Project	Parameter
1	Power supply	220V,50Hz
2	Extrusion force	1.5KN
3	Pressure speed	50±5mm/min
4	Pressure plate specification	Length 100mm, width 50mm, long side rounded R1mm
5	Sample placement	at a right Angle to the long side, 350mm away
6	Pressure mode	electric type
7	Size	1000x500x1500mm
8	Weight	200kg

Picture for reference:
